Multi-Cylinder Metal Baler

Home >
Products >
Multi-Cylinder Metal Baler

Product Features

Key Parameters	Y81-315	Y81-500	Y81-630	Y81-1000	Y81-1500	Y81-2000	Y81-2500	Y81-3000	Y81-4000
Main cylinder nominal thrust rating（t）	315	500	630	1000	1500	2000	2500	3000	4000
Package cross-sectional size（mm）	600×600Square Bale or 300×300Octagonal Bale	600×600 or 700×700	600×600 or 700×700	600×600 or 700×700	600×600 or 700×700	600×600 or 700×700	700×700 or 800×800	700×700 or 800×800	700×700 or 800×800
Material Box Size (Length × Width × Height)（mm）	2500×2000 ×1000	3000×2500 ×1100	3500×3000 ×1200	3500×3000 ×1300	4000×3000 ×1400	4000×3000 ×1500	4000×3000 ×1600	4000×3000 ×1700	4000×3000 ×1700
Main Motor Power (kW)	41(1×41)	76(1×76)	90 (1×90)	134 (2×67)	201 (3×67)	304 (4×76)	360 (4×90)	450 (5×90)	540 (6×90)

Product Features

Main Cylinder Wor
ry-Free: Utilizing patented multi-main cylinder technology, it effectively resolves the series of pain points associated with traditional single-main cylinders, ensuring wor
ry-free main cylinder operation.
Reliable Quality: The entire machine is built to engineering machinery quality standards. The main cylinder's quality and service life are comparable to those of engineering mechanical hydraulic cylinders, ensuring trouble-free operation, reliability, and peace of mind.
Lower Costs: Reduced operating costs with installed power decreased by approximately 30%, saving about 150,000 CNY annually in electricity expenses, and hydraulic oil usage reduced by roughly 50%
